Technical Guidance
Leapion machines come with a 3-year warranty, 24/7 online technical guidance. and comprehensive pre-sales sales and after-sales services to provide you with the best
shopping and using experience.
shopping and using experience.
Mode | ST3-A | ST3-B |
---|---|---|
Maximum processing Length | 6000mm | 6000mm |
Unloading Length | 3000mm | 3000mm |
Power Support | 6000-20000w | 6000-20000w |
ProcessingPipe Size | 20-360mm | 40-550mm |
Dimenison(L*W*H) | 17500*2800*2800mm | 17500*2800*3300 |
Chuck Rotation Speed | 100R/min | 60R/min |
Chuck Weighing | 1100kg | 2000kg |
Maxium Idle Running Speed | 75m/min | 60m/min |
Maximum Idle Acceleration | 0.8G | 0.6G |
Positioning Accuracy | 0.03mm | 0.03mm |
Repeat Positioning Accuracy | 0.02mm | 0.02mm |
Support Device | Follow-up | Follow-up |
Feeding Device(Optional) | Automatice | Automatice |
Technical Guidance
7% Discount
